Sector Rotation Chart

Display only

Indicator Disclaimer | Report this indicator

Screenshot of Sector Rotation Chart indicator

General Idea

This indicator creates a Sector Rotation Chart that visualizes how multiple sectors (or any symbols) are performing relative to a benchmark over time. The core concept is displaying each sector's path as a spiral on a circular chart, where the position indicates the sector's relative strength and momentum compared to the benchmark, while the distance from center represents time progression.

How It Works

The chart divides performance into 8 distinct phases (octants) arranged in a circle, such as "Strong leader," "Accelerating," "Bottoming," and "Deep laggard." Each sector's journey through these phases is traced as a spiral path that grows outward from the center, with the oldest data points near the center and the most recent at the rim.

The position of each point on the spiral is determined by two factors: how the sector is performing relative to the benchmark (relative strength), and whether that relative performance is improving or deteriorating (momentum). The spiral can wind clockwise through the phases as a sector rotates through different performance stages, or reverse direction when the sector's trajectory changes.

Visual Elements

The chart includes several visual aids: concentric rings marking time periods, directional arrows showing the path direction, and color-coded background slices for each performance phase. Each sector's path is drawn in its own color, with dot sizes varying based on trading volume. The final position of each sector is labeled with its symbol and the total degrees it has rotated, giving a quick summary of its journey.

Usage

This tool helps traders identify which sectors are currently leading or lagging the market, and more importantly, which sectors are transitioning between phases. A sector spiraling clockwise from "Bottoming" through "Turning up" to "Accelerating" suggests strengthening relative performance, while a reversal pattern might indicate a sector losing momentum. The visual nature makes it easy to spot rotation patterns and timing of sector shifts at a glance.

describe_indicator('Sector Rotation Chart v6', 'price');

const VERBOSE_INPUT_OPTIONS = { hide_in_legend: true };

const tinycolor = library('tinycolor2');

//	applies an alpha to any user-picked color (hex or named)
const withAlpha = (color, alpha) => tinycolor(color).setAlpha(alpha).toRgbString();

const enableSector1 = input.boolean('Show 1', true, VERBOSE_INPUT_OPTIONS);
const mySector1 = input.symbol('Symbol 1', 'XLE', VERBOSE_INPUT_OPTIONS);
const myColor1 = input.color('Color 1', '#FF5722', VERBOSE_INPUT_OPTIONS);
const enableSector2 = input.boolean('Show 2', true, VERBOSE_INPUT_OPTIONS);
const mySector2 = input.symbol('Symbol 2', 'XLB', VERBOSE_INPUT_OPTIONS);
const myColor2 = input.color('Color 2', '#795548', VERBOSE_INPUT_OPTIONS);
const enableSector3 = input.boolean('Show 3', true, VERBOSE_INPUT_OPTIONS);
const mySector3 = input.symbol('Symbol 3', 'XLI', VERBOSE_INPUT_OPTIONS);
const myColor3 = input.color('Color 3', '#607D8B', VERBOSE_INPUT_OPTIONS);
const enableSector4 = input.boolean('Show 4', true, VERBOSE_INPUT_OPTIONS);
const mySector4 = input.symbol('Symbol 4', 'XLY', VERBOSE_INPUT_OPTIONS);
const myColor4 = input.color('Color 4', '#FFA500', VERBOSE_INPUT_OPTIONS);
const enableSector5 = input.boolean('Show 5', false, VERBOSE_INPUT_OPTIONS);
const mySector5 = input.symbol('Symbol 5', 'XLP', VERBOSE_INPUT_OPTIONS);
const myColor5 = input.color('Color 5', '#28A745', VERBOSE_INPUT_OPTIONS);
const enableSector6 = input.boolean('Show 6', true, VERBOSE_INPUT_OPTIONS);
const mySector6 = input.symbol('Symbol 6', 'XLV', VERBOSE_INPUT_OPTIONS);
const myColor6 = input.color('Color 6', '#DC3545', VERBOSE_INPUT_OPTIONS);
const enableSector7 = input.boolean('Show 7', true, VERBOSE_INPUT_OPTIONS);
const mySector7 = input.symbol('Symbol 7', 'XLF', VERBOSE_INPUT_OPTIONS);
const myColor7 = input.color('Color 7', '#1E90FF', VERBOSE_INPUT_OPTIONS);
const enableSector8 = input.boolean('Show 8', true, VERBOSE_INPUT_OPTIONS);
const mySector8 = input.symbol('Symbol 8', 'XLK', VERBOSE_INPUT_OPTIONS);
const myColor8 = input.color('Color 8', '#00BCD4', VERBOSE_INPUT_OPTIONS);
const enableSector9 = input.boolean('Show 9', false, VERBOSE_INPUT_OPTIONS);
const mySector9 = input.symbol('Symbol 9', 'XLC', VERBOSE_INPUT_OPTIONS);
const myColor9 = input.color('Color 9', '#9C27B0', VERBOSE_INPUT_OPTIONS);
const enableSector10 = input.boolean('Show 10', false, VERBOSE_INPUT_OPTIONS);
const mySector10 = input.symbol('Symbol 10', 'XLU', VERBOSE_INPUT_OPTIONS);
const myColor10 = input.color('Color 10', '#6366F1', VERBOSE_INPUT_OPTIONS);
const enableSector11 = input.boolean('Show 11', false, VERBOSE_INPUT_OPTIONS);
const mySector11 = input.symbol('Symbol 11', 'XLRE', VERBOSE_INPUT_OPTIONS);
const myColor11 = input.color('Color 11', '#009688', VERBOSE_INPUT_OPTIONS);
const myBenchmark = input.symbol('Benchmark', 'VTI');

const myCalcTimeframe = input.select('Timeframe', 'Weekly', ['Weekly', 'Monthly']);
const myHistoryLength = input.number('Tail length', 5, { min: 2, max: 100 });
const mySolidBackground = input.boolean('Solid background', true);

//	octant slice colors: one picker per slice. The picked color drives both
//	the slice's background fill (alpha applied programmatically) and its
//	edge label. Defaults match the original palette.
const myOctantColor1 = input.color('Slice: Strong leader', '#32CD32', VERBOSE_INPUT_OPTIONS);
const myOctantColor2 = input.color('Slice: Accelerating', '#9ACD32', VERBOSE_INPUT_OPTIONS);
const myOctantColor3 = input.color('Slice: Turning up', '#4DD0E1', VERBOSE_INPUT_OPTIONS);
const myOctantColor4 = input.color('Slice: Bottoming', '#AAAAAA', VERBOSE_INPUT_OPTIONS);
const myOctantColor5 = input.color('Slice: Deep laggard', '#DC3545', VERBOSE_INPUT_OPTIONS);
const myOctantColor6 = input.color('Slice: Falling', '#E57373', VERBOSE_INPUT_OPTIONS);
const myOctantColor7 = input.color('Slice: Rolling over', '#FFA726', VERBOSE_INPUT_OPTIONS);
const myOctantColor8 = input.color('Slice: Losing steam', '#AAAAAA', VERBOSE_INPUT_OPTIONS);

const CHART_SIZE_MAP = {
	small: { w: 450, h: 300 },
	medium: { w: 600, h: 400 },
	large: { w: 900, h: 600 },
	xlarge: { w: 1200, h: 800 }
};

const tableDimensions = CHART_SIZE_MAP[input.select('Chart size', 'medium', Object.keys(CHART_SIZE_MAP))];

const SECTORS = [{
	ticker: mySector1,
	color: myColor1,
	enabled: enableSector1
}, {
	ticker: mySector2,
	color: myColor2,
	enabled: enableSector2
}, {
	ticker: mySector3,
	color: myColor3,
	enabled: enableSector3
}, {
	ticker: mySector4,
	color: myColor4,
	enabled: enableSector4
}, {
	ticker: mySector5,
	color: myColor5,
	enabled: enableSector5
}, {
	ticker: mySector6,
	color: myColor6,
	enabled: enableSector6
}, {
	ticker: mySector7,
	color: myColor7,
	enabled: enableSector7
}, {
	ticker: mySector8,
	color: myColor8,
	enabled: enableSector8
}, {
	ticker: mySector9,
	color: myColor9,
	enabled: enableSector9
}, {
	ticker: mySector10,
	color: myColor10,
	enabled: enableSector10
}, {
	ticker: mySector11,
	color: myColor11,
	enabled: enableSector11
}].filter(sector => sector.enabled);

const myDataResolution = myCalcTimeframe === 'Weekly' ? 'W' : 'M';
const allSymbolsToFetch = [myBenchmark, ...SECTORS.map(sector => sector.ticker)];
const allDataPromises = allSymbolsToFetch.map(ticker => request.history(ticker, myDataResolution));

let allDataResults;

try {
	allDataResults = await Promise.all(allDataPromises);
}
catch (exception) {
	throw "Failed to fetch historical data. This may be due to an invalid ticker symbol or network issue.";
}

const benchmarkData = allDataResults[0];
assert(!benchmarkData.error, `Error fetching ${myBenchmark} data: ${benchmarkData.error}`);

const computeChangePercentValue = (dataSeries, value, dummy, index) => index < myHistoryLength
	? null
	: (value - dataSeries[index - myHistoryLength]) / dataSeries[index - myHistoryLength];

const benchmarkChange = for_every(benchmarkData.close, computeChangePercentValue.bind(null, benchmarkData.close));

const sectorRSData = [];
const sectorRSMomentumData = [];
const sectorVolumeData = [];

for (let i = 0; i < SECTORS.length; i++) {
	const sector = SECTORS[i];
	const thisDataSeries = allDataResults[i + 1];

	const sectorPrice = land_points_onto_series(thisDataSeries.time, thisDataSeries.close, benchmarkData.time);

	const volumeTail = thisDataSeries.volume.slice(-(myHistoryLength + 1));

	const maxSectorVolume = Math.max(...volumeTail);
	const minSectorVolume = Math.min(...volumeTail);
	const sectorVolumeRange = Math.max(1, maxSectorVolume - minSectorVolume);

	const sectorVolume = volumeTail.map(value => (value - minSectorVolume) / sectorVolumeRange);
	const sectorPriceChange = for_every(sectorPrice, computeChangePercentValue.bind(null, sectorPrice));

	const EPSILON = 1;

	const myRelativeStrength = for_every(sectorPriceChange, benchmarkChange, (_sectorChange, _benchmarkChange) => {
		if (_sectorChange === null || _benchmarkChange === null) {
			return null;
		}

		return (_sectorChange + EPSILON) / (_benchmarkChange + EPSILON);
	});

	const myRSMomentum = for_every(myRelativeStrength, (_currentRS, _prevOutput, _index) => {
		if (_index < 1 || _currentRS === null) {
			return null;
		}

		const previousRS = myRelativeStrength[_index - 1];

		if (previousRS === null || previousRS === 0) {
			return null;
		}

		return (_currentRS / previousRS) * 100;
	});

	sectorRSData.push(myRelativeStrength.slice(-myHistoryLength));
	sectorRSMomentumData.push(myRSMomentum.slice(-myHistoryLength));
	sectorVolumeData.push(sectorVolume);
}

//	========================================================================
//	SPIRAL TRANSFORM
//	Each (RS, momentum) observation collapses to a phase angle around the
//	(100, 100) center: theta = atan2(momentum - 100, RS - 100).
//	Angles are UNWRAPPED across time (each step adjusted by +/-360 to take
//	the smallest move) so direction and turn count survive the 0/360 seam.
//	Radius encodes TIME: oldest observation near the center, newest at the
//	rim. A path can never overlap itself. Clockwise winding = forward
//	rotation (Outperforming -> Degrading -> ...), a switchback = reversal.
//	========================================================================

const CX = 100;
const CY = 100;
const HALF_RANGE = 10;		// data-units from center to rim, both axes
const AXIS_PAD = 1.05;		// extra room outside the rim for labels
const INNER_RADIUS_FRAC = 0.18;	// radius fraction of the oldest point

//	the canvas is wider than tall; widening ONLY the x-axis range by the
//	aspect ratio makes pixels-per-unit equal on both axes, so rings render
//	as true circles and angles are undistorted
const ASPECT = tableDimensions.w / tableDimensions.h;

const minX = CX - HALF_RANGE * AXIS_PAD * ASPECT;
const maxX = CX + HALF_RANGE * AXIS_PAD * ASPECT;
const minY = CY - HALF_RANGE * AXIS_PAD;
const maxY = CY + HALF_RANGE * AXIS_PAD;

const DEG = Math.PI / 180;

//	polar (degrees, radius fraction 0..1) -> chart data-space, OCTAGON
//	geometry. The rim is a regular octagon with vertices at the slice
//	boundaries (0/45/90/...), so each octant's rim is one flat edge.
//	Distance to the rim along a ray = apothem / cos(offset from the edge
//	center); frac = 1 lands exactly on the octagon in every direction.
const OCT_APOTHEM = Math.cos(22.5 * DEG);

const polarToXY = (angleDeg, radiusFrac) => {
	const norm = ((angleDeg % 360) + 360) % 360;
	const offsetFromEdgeCenter = norm - (Math.floor(norm / 45) * 45 + 22.5);
	const t = radiusFrac * HALF_RANGE * OCT_APOTHEM / Math.cos(offsetFromEdgeCenter * DEG);

	return {
		x: CX + t * Math.cos(angleDeg * DEG),
		y: CY + t * Math.sin(angleDeg * DEG)
	};
};

//	smallest signed angular difference, result in (-180, 180]
const wrapDelta = (delta) => ((delta % 360) + 540) % 360 - 180;

const radiusAt = (stepIndex, totalSteps) => totalSteps <= 1
	? 1
	: INNER_RADIUS_FRAC + (1 - INNER_RADIUS_FRAC) * (stepIndex / (totalSteps - 1));

//	screen-space rotation (degrees, clockwise, 0 = pointing up) for a
//	Chart.js triangle pointStyle so it points along the path tangent.
//	Accounts for unequal axis ranges, unequal pixel dimensions, and the
//	flipped screen y axis.
const screenRotation = (fromPt, toPt) => {
	const dxScreen = (toPt.x - fromPt.x) / (maxX - minX) * tableDimensions.w;
	const dyScreen = -(toPt.y - fromPt.y) / (maxY - minY) * tableDimensions.h;

	return Math.atan2(dyScreen, dxScreen) / DEG + 90;
};

const MIN_DOT_SIZE = 0.5;
const MAX_DOT_SIZE = 6;
const INTERP_DEGREES_PER_DOT = 2;	// path dot density along the angular sweep
const MIN_DOTS_PER_SEGMENT = 10;

const chartDatasets = [];
const labelAnnotations = {};
const placedLabels = [];

for (let i = 0; i < SECTORS.length; i++) {
	const sectorTicker = SECTORS[i].ticker;
	const sectorColor = SECTORS[i].color;

	//	pair up RS and momentum, dropping leading nulls but preserving
	//	the volume index alignment via the original step index
	const observations = [];

	for (let candleIdx = 0; candleIdx < sectorRSData[i].length; candleIdx++) {
		const rsValue = sectorRSData[i][candleIdx];
		const momentumValue = sectorRSMomentumData[i][candleIdx];

		if (rsValue === null || momentumValue === null || !isFinite(rsValue) || !isFinite(momentumValue)) {
			continue;
		}

		observations.push({
			rawAngle: Math.atan2(momentumValue - 100, rsValue * 100 - 100) / DEG,
			volume: sectorVolumeData[i][candleIdx] ?? 0
		});
	}

	if (observations.length < 2) {
		continue;
	}

	//	unwrap
	const angles = [observations[0].rawAngle];

	for (let k = 1; k < observations.length; k++) {
		angles.push(angles[k - 1] + wrapDelta(observations[k].rawAngle - angles[k - 1]));
	}

	const totalSteps = angles.length;

	//	interpolated spiral path: dots only, volume-sized, linear in
	//	unwrapped angle and in radius within each segment
	const interpData = [];
	const interpRadii = [];
	const arrowData = [];
	const arrowRotations = [];

	for (let k = 0; k < totalSteps - 1; k++) {
		const angleSpan = Math.abs(angles[k + 1] - angles[k]);
		const steps = Math.max(MIN_DOTS_PER_SEGMENT, Math.round(angleSpan / INTERP_DEGREES_PER_DOT));

		const vol1 = observations[k].volume;
		const vol2 = observations[k + 1].volume;

		for (let s = 0; s < steps; s++) {
			const t = s / steps;
			const angle = angles[k] + (angles[k + 1] - angles[k]) * t;
			const radius = radiusAt(k + t, totalSteps);

			interpData.push(polarToXY(angle, radius));

			const vol = vol1 + (vol2 - vol1) * t;
			interpRadii.push(MIN_DOT_SIZE + vol * (MAX_DOT_SIZE - MIN_DOT_SIZE));
		}

		//	one direction arrow per segment, at the segment midpoint,
		//	rotated to the local tangent of the interpolated path
		const midAngle = angles[k] + (angles[k + 1] - angles[k]) * 0.5;
		const midRadius = radiusAt(k + 0.5, totalSteps);
		const tangentStep = 0.02;
		const tangentAngle = angles[k] + (angles[k + 1] - angles[k]) * (0.5 + tangentStep);
		const tangentRadius = radiusAt(k + 0.5 + tangentStep, totalSteps);

		const midPoint = polarToXY(midAngle, midRadius);
		const aheadPoint = polarToXY(tangentAngle, tangentRadius);

		arrowData.push(midPoint);
		arrowRotations.push(screenRotation(midPoint, aheadPoint));
	}

	chartDatasets.push({
		label: `${sectorTicker}_interp`,
		data: interpData,
		showLine: false,
		borderWidth: 0,
		backgroundColor: withAlpha(sectorColor, 0.7),
		borderColor: withAlpha(sectorColor, 0.7),
		pointRadius: interpRadii,
		pointStyle: 'circle'
	});

	chartDatasets.push({
		label: `${sectorTicker}_arrows`,
		data: arrowData,
		showLine: false,
		borderWidth: 0,
		backgroundColor: sectorColor,
		borderColor: sectorColor,
		pointRadius: 5,
		pointStyle: 'triangle',
		rotation: arrowRotations
	});

	//	observation markers: small dots, larger dot at "now" (the rim)
	const markerData = angles.map((angle, k) => polarToXY(angle, radiusAt(k, totalSteps)));

	chartDatasets.push({
		label: sectorTicker,
		data: markerData,
		showLine: false,
		borderWidth: 0,
		backgroundColor: sectorColor,
		borderColor: sectorColor,
		pointRadius: markerData.map((_, pointIndex) => pointIndex === totalSteps - 1 ? 5 : 2),
		pointStyle: 'circle'
	});

	const lastPoint = markerData[totalSteps - 1];
	const netRotation = Math.round(angles[totalSteps - 1] - angles[0]);

	//	collision avoidance: stack clustered labels away from the point in
	//	14px steps; labels flip BELOW the point when the endpoint is near
	//	the top edge so they don't clip the tighter frame
	const LABEL_X_CLEARANCE = 2.4;	// data units
	const LABEL_Y_CLEARANCE = 0.9;	// data units
	const LABEL_STACK_PX = 14;

	const nearTop = lastPoint.y > CY + 0.8 * HALF_RANGE;
	const stackDir = nearTop ? 1 : -1;

	let yAdjust = 10 * stackDir;
	let collided = true;
	let guard = 0;

	while (collided && guard < 12) {
		collided = placedLabels.some(placed =>
			Math.abs(lastPoint.x - placed.x) < LABEL_X_CLEARANCE &&
			Math.abs(lastPoint.y - placed.y) < LABEL_Y_CLEARANCE &&
			Math.abs(yAdjust - placed.yAdjust) < LABEL_STACK_PX
		);

		if (collided) {
			yAdjust += LABEL_STACK_PX * stackDir;
		}

		guard++;
	}

	placedLabels.push({ x: lastPoint.x, y: lastPoint.y, yAdjust });

	labelAnnotations[`label_${i}`] = {
		type: 'label',
		xValue: lastPoint.x,
		yValue: lastPoint.y,
		content: [`${sectorTicker} ${netRotation > 0 ? '+' : ''}${netRotation}u00B0`],
		color: sectorColor,
		font: { size: 11, weight: 'bold' },
		position: { x: 'center', y: nearTop ? 'bottom' : 'top' },
		textStrokeColor: mySolidBackground ? 'black' : 'var(--background-color)',
		textStrokeWidth: 2,
		xAdjust: 0,
		yAdjust
	};
}

//	time rings: drawn at the SAME radii the data points use (radiusAt), so
//	rings are evenly spaced and labels land exactly on observation circles.
//	For long tails, periods are subsampled evenly to at most MAX_RINGS.
const ringAnnotations = {};
const MAX_RINGS = 8;
const totalPeriods = myHistoryLength;
const ringCount = Math.min(totalPeriods - 1, MAX_RINGS);

for (let ringIdx = 1; ringIdx <= ringCount; ringIdx++) {
	//	fractional period position -> perfectly uniform ring gaps at any
	//	tail length; exact data radii whenever (tail - 1) <= MAX_RINGS
	const periodPos = ringIdx * (totalPeriods - 1) / ringCount;
	const frac = radiusAt(periodPos, totalPeriods);
	const rx = frac * HALF_RANGE;
	const ry = frac * HALF_RANGE;

	const periodsBack = Math.round((totalPeriods - 1) - periodPos);
	const isNowRing = periodsBack === 0;

	//	recency ramp: oldest rings dim, newest bright, "now" highlighted
	const recency = ringIdx / ringCount;
	const ringColor = isNowRing
		? 'rgba(255, 255, 255, 0.7)'
		: `rgba(160, 160, 160, ${(0.15 + 0.35 * recency).toFixed(2)})`;

	//	octagon ring outline as a line dataset: 9 points through the
	//	vertices (slice boundaries), exact in data space. order 98 puts
	//	rings above the wedge fills (99) and below all sector data (0).
	const ringPts = [];

	for (let v = 0; v <= 8; v++) {
		ringPts.push(polarToXY(v * 45, frac));
	}

	chartDatasets.push({
		label: `_ring_${ringIdx}`,
		data: ringPts,
		showLine: true,
		fill: false,
		borderColor: ringColor,
		borderWidth: isNowRing ? 1.5 : 1,
		pointRadius: 0,
		pointHitRadius: 0,
		tension: 0,
		order: 98
	});

	ringAnnotations[`ring_${ringIdx}_label`] = {
		type: 'label',
		xValue: CX,
		yValue: CY + frac * HALF_RANGE,
		content: [isNowRing ? 'now' : `-${periodsBack}`],
		color: isNowRing ? 'rgba(255, 255, 255, 0.8)' : `rgba(170, 170, 170, ${(0.3 + 0.4 * recency).toFixed(2)})`,
		font: { size: 9 },
		position: { x: 'center', y: 'start' },
		drawTime: 'beforeDatasetsDraw'
	};
}

//	========================================================================
//	OCTANT SLICES
//	The chart is cut into 8 pizza slices. The main crosshair (RS and
//	momentum axes) stays prominent; the 45-degree diagonals are fainter.
//	Each slice is labeled just outside the midpoint of its octagon edge.
//	Slice colors are user inputs: the picked color drives the label at
//	full opacity and the background fill at the slice's fixed alpha.
//	========================================================================

const OCTANTS = [
	{ centerAngle: 22.5,  label: 'Strong leader', color: myOctantColor1, fillAlpha: 0.10 },
	{ centerAngle: 67.5,  label: 'Accelerating',  color: myOctantColor2, fillAlpha: 0.07 },
	{ centerAngle: 112.5, label: 'Turning up',    color: myOctantColor3, fillAlpha: 0.07 },
	{ centerAngle: 157.5, label: 'Bottoming',     color: myOctantColor4, fillAlpha: 0.05 },
	{ centerAngle: 202.5, label: 'Deep laggard',  color: myOctantColor5, fillAlpha: 0.10 },
	{ centerAngle: 247.5, label: 'Falling',       color: myOctantColor6, fillAlpha: 0.07 },
	{ centerAngle: 292.5, label: 'Rolling over',  color: myOctantColor7, fillAlpha: 0.07 },
	{ centerAngle: 337.5, label: 'Losing steam',  color: myOctantColor8, fillAlpha: 0.05 }
];

const octantAnnotations = {};

//	diagonal slice boundaries (the 0/90/180/270 boundaries are the
//	existing crosshair lines)
[45, 135, 225, 315].forEach((boundaryAngle, idx) => {
	const edge = polarToXY(boundaryAngle, 1);

	octantAnnotations[`octantBoundary_${idx}`] = {
		type: 'line',
		xMin: CX,
		xMax: edge.x,
		yMin: CY,
		yMax: edge.y,
		borderColor: 'rgba(128, 128, 128, 0.25)',
		borderWidth: 1,
		borderDash: [4, 4],
		drawTime: 'beforeDatasetsDraw'
	};
});

OCTANTS.forEach((octant, idx) => {
	//	label just outside the midpoint of this slice's octagon edge
	const labelPoint = polarToXY(octant.centerAngle, 1.1);

	octantAnnotations[`octantLabel_${idx}`] = {
		type: 'label',
		xValue: labelPoint.x,
		yValue: labelPoint.y,
		position: { x: 'center', y: 'center' },
		content: [octant.label],
		color: octant.color,
		font: { size: 12, weight: 'bold' },
		padding: 5
	};

	//	pizza-slice background fill: a closed line dataset tracing
	//	center -> rim arc -> center, filled by the Filler plugin.
	//	order: 99 + appended last = drawn behind all sector datasets.
	const wedgeData = [{ x: CX, y: CY }];
	const startAngle = octant.centerAngle - 22.5;
	const ARC_STEP_DEG = 3;

	for (let a = 0; a <= 45; a += ARC_STEP_DEG) {
		wedgeData.push(polarToXY(startAngle + a, 1));
	}

	wedgeData.push({ x: CX, y: CY });

	chartDatasets.push({
		label: `_octant_fill_${idx}`,
		data: wedgeData,
		showLine: true,
		fill: 'shape',
		backgroundColor: withAlpha(octant.color, octant.fillAlpha),
		borderWidth: 0,
		borderColor: 'transparent',
		pointRadius: 0,
		pointHitRadius: 0,
		tension: 0,
		order: 99
	});
});

paint_overlay('Chart', {
	position: 'bottom_left',
	offset_x: 0,
	offset_y: 0,
	order: 'above_all'
}, {
	rows: [{
		cells: [{
			chart: {
				width: `${tableDimensions.w}px`,
				height: `${tableDimensions.h}px`,
				type: 'scatter',
				options: {
					showLine: false,
					scales: {
						x: {
							type: 'linear',
							min: minX,
							max: maxX,
							ticks: { display: false },
							title: { display: false },
							border: { display: false },
							grid: { display: false }
						},
						y: {
							type: 'linear',
							min: minY,
							max: maxY,
							ticks: { display: false },
							title: { display: false },
							border: { display: false },
							grid: { display: false }
						}
					},
					plugins: {
						legend: { display: false },
						annotation: {
							annotations: {
								...(mySolidBackground ? {
									chartBackground: {
										type: 'box',
										xMin: minX,
										xMax: maxX,
										yMin: minY,
										yMax: maxY,
										backgroundColor: 'rgba(0, 0, 0, 0.92)',
										borderWidth: 0,
										drawTime: 'beforeDraw'
									}
								} : {}),
								...ringAnnotations,
								verticalLine: {
									type: 'line',
									xMin: CX,
									xMax: CX,
									yMin: CY - HALF_RANGE,
									yMax: CY + HALF_RANGE,
									borderColor: 'rgba(128, 128, 128, 0.5)',
									borderWidth: 2,
									borderDash: [5, 5],
									drawTime: 'beforeDatasetsDraw'
								},
								horizontalLine: {
									type: 'line',
									yMin: CY,
									yMax: CY,
									xMin: CX - HALF_RANGE,
									xMax: CX + HALF_RANGE,
									borderColor: 'rgba(128, 128, 128, 0.5)',
									borderWidth: 2,
									borderDash: [5, 5],
									drawTime: 'beforeDatasetsDraw'
								},
								...octantAnnotations,
								...labelAnnotations
							}
						}
					}
				},
				data: {
					datasets: chartDatasets
				}
			}
		}]
	}]
});

Add to TrendSpider

Terms and Conditions

THE INFORMATION PROVIDED THROUGH ANY CONTENT (“CONTENT”) PUBLISHED ON OR PROVIDED THROUGH THE MARKETPLACE (“MARKETPLACE”) SUPPORTED BY TRENDSPIDER LLC (“TRENDSPIDER”) IS PROVIDED "AS IS" AND "AS AVAILABLE" BY THIRD PARTIES AND NOT BY TRENDSPIDER OR ANY OF ITS AFFILIATES. TRENDSPIDER DOES NOT WARRANT THE ACCURACY, COMPLETENESS OR TIMELINESS OF ANY MARKET INFORMATION, FEATURES, TOOLS OR OTHER ITEMS (“INFORMATION”) MADE AVAILABLE THROUGH ANY CONTENT. TRENDSPIDER EXPRESSLY DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, PERTAINING TO THE MARKETPLACE, THE CONTENT OR ANY INFORMATION MADE AVAILABLE THROUGH ANY CONTENT, INCLUDING, WITHOUT LIMITIATION, IMPLIED WARRANTIES OF MERCHANTABILITY, ACCURACY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT. TRENDSPIDER EXPRESSLY DISCLAIMS ALL LIABILITY FOR ERRORS OR OMISSIONS IN, OR THE MISUSE OR MISINTERPRETATION OF, ANY INFORMATION MADE AVAILABLE THROUGH ANY CONTENT.

YOU ASSUME THE ENTIRE RISK AS TO THE USE OF ANY INFORMATION MADE AVAILABLE THROUGH ANY CONTENT. UNDER NO CIRCUMSTANCES WILL TRENDSPIDER OR ITS AFFILIATES, AGENTS, OR EMPLOYEES BE LIABLE FOR ANY DAMAGES OF ANY KIND THAT RESULT FROM THE USE OF, OR THE INABILITY TO USE, ANY CONTENT, OR ANY RELAINCE ON ANY INFORMATION MADE AVAILABLE THROUGH ANY CONTENT, EVEN IF ANY SUCH PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

The Content is for informational, educational and entertainment purposes only. Although Content may make available Information relating to investment approaches and opportunities to buy or sell securities, you should not construe any Information made available through any Content as legal, tax, investment, financial or other advice. Nothing contained in any Content constitutes a solicitation, recommendation, endorsement, or offer to buy or sell any securities or other financial instruments. Investing involves risk and you alone assume the sole responsibility of evaluating the merits and risks associated with the use of any Information made available through any Content before making any decisions. You agree not to hold TrendSpider or its affiliates, agents or employees liable for any possible claim for damages arising from any decision you make based on Information made available through any Content.

Some free Content may require a separate subscription to paid Content in order to fully function. TrendSpider makes no representation or warranty as to the level of functionality of any Content offered on the Marketplace and hereby expressly disclaims any such warranty.

Unless otherwise indicated in the Marketplace, TrendSpider is not responsible for billing or user entitlement matters. Any issues pertaining these matters should be directed to the publisher of the Content.

Cancel Accept and continue

Disclaimer

Report This Indicator

General Idea

How It Works

Visual Elements

Usage

Traders also viewed
