What It Does

The IFVG indicator identifies Fair Value Gaps (price imbalances) that undergo directional inversions – a key ICT trading concept. It tracks how institutional order flow transforms these gaps from bullish to bearish zones (or vice versa), revealing high-probability reversal and continuation areas.

How It Works

Fair Value Gaps occur when price moves so fast it leaves unfilled ranges – areas where institutional traders weren’t efficiently matched.

Inversions happen when price breaks through a gap, completely flipping its directional bias:

Bullish gap → Price breaks below → Becomes bearish supply zone
Bearish gap → Price breaks above → Becomes bullish demand zone

Visual Features

Pre-Inversion: Original gap color (green=bullish, red=bearish)
Post-Inversion: Opposite color after the flip occurs
Midlines: Dotted gray lines mark gap centers
Inversion Dots: Show exact transformation points
Smart Display: Only shows recent inversions to keep charts clean

Signals

Generates trading alerts when price retests inverted zones:

Bullish: Price retests top of bullish-inverted zone
Bearish: Price retests bottom of bearish-inverted zone

Use for entries, alerts, scanners, and automated strategies.

Best Markets & Timeframes

Optimal Performance:

Futures: NQ (Nasdaq), ES (S&P 500) – excellent institutional footprints
Crypto: ETH, BTC, SOL – higher timeframes work best

Timeframe Guide:

Traditional Markets: All timeframes during regular hours
Crypto: 15M+ preferred due to fragmented liquidity
Exception: Lower timeframes work during NY session (peak crypto liquidity)

Key Settings

ATR Multiplier: Filters noise (0.25-0.5 for most markets)
Wick vs Close Retest: Choose signal sensitivity
Show Seeds: Optional pre-inversion gap display

Why These Markets?

High institutional participation creates clear FVG patterns and reliable inversions. The algorithm uses ATR filtering to ensure only significant imbalances are tracked, not random noise.

Educational Value

Learn institutional market mechanics through clear visual representation. Practice identifying patterns manually while getting precise algorithmic detection. Best used with confluence from order blocks, liquidity sweeps, and higher timeframe bias.

Open Source

Created by John Wolff

Completely free and open source. Modify, improve, and share as you wish.

Understanding the "why" behind price movements matters more than blindly following signals.

describe_indicator('Inversion Fair Value Gaps (IFVG)', 'price', { shortName: 'IFVG' });

// =============================================================================


// Inputs
const disp_num = input.number('Show Last', 5, { min: 1, max: 100 });
const useWickRetest = input.boolean('Use Wick for Signals', false);
const atr_multi = input.number('ATR Multiplier', 0.25, { min: 0, max: 10, step: 0.25 });
const proj_len = input.number('Projection Bars', 50, { min: 0, max: 200 });

// Optional features
const showSeeds = input.boolean('Show Pre-Inversion Seeds?', false);
const showInversionDots = input.boolean('Show Inversion Points?', true);
const extendZones = input.boolean('Extend Active Zones?', true);
const showMidlines = input.boolean('Show Zone Midlines?', true);
// NEW: optional color mode that paints zones by supply/demand location relative to current price
const colorByLocation = input.boolean('Color Zones by Location (Above Price = Red, Below = Green)?', false);

// Session gap filtering (for stocks)
const filterSessionGaps = input.boolean('Filter Session Gaps?', true);
const sessionGapThreshold = input.number('Session Gap Threshold %', 0.1, { min: 0, max: 5, step: 0.1 });

// Colors
const green = '#08998150';  // Bullish color with transparency
const red = '#f2364550';    // Bearish color with transparency
const midCol = '#787b86';   // Midline color

// Data validation
if (!high || !low || !open || !close || close.length < 3) {
    console.error('Insufficient price data - need at least 3 bars');
}

// Body high/low calculations
const c_top = high.map((_, i) => {
    if (open[i] == null || close[i] == null) return null;
    return Math.max(open[i], close[i]);
});
const c_bot = low.map((_, i) => {
    if (open[i] == null || close[i] == null) return null;
    return Math.min(open[i], close[i]);
});

// ATR calculation
const atr200 = atr(200);
const minWidth = series_of(null);
let cumulativeRange = 0;

for (let i = 0; i < close.length; i++) {
    if (high[i] != null && low[i] != null && high[i] >= low[i]) {
        cumulativeRange += (high[i] - low[i]);
    }

    const atrValue = (atr200[i] !== null && atr200[i] !== undefined && atr200[i] > 0) ?
        atr200[i] :
        (cumulativeRange / (i + 1));

    minWidth[i] = Math.max(0, atrValue * atr_multi);
}

// Data structures
const BUFFER = 100;
let bulls = [];
let bears = [];
let bullInv = [];
let bearInv = [];

// Signal series
const bullRet = series_of(false);
const bearRet = series_of(false);
const inversionDots = series_of(null);

// Optional seed visualization
const seedTop = series_of(null);
const seedBot = series_of(null);

// Simple drawing approach - pre-allocate series for zones
const maxZones = Math.min(disp_num * 2, 15); // Reasonable limit
const preTopSeries = [];
const preBotSeries = [];
const postTopSeries = [];
const postBotSeries = [];
const midSeries = [];

// Initialize drawing series
for (let k = 0; k < maxZones; k++) {
    preTopSeries[k] = series_of(null);
    preBotSeries[k] = series_of(null);
    postTopSeries[k] = series_of(null);
    postBotSeries[k] = series_of(null);
    midSeries[k] = series_of(null);
}

// Debug counters
let debugCounters = {
    bullFVGsDetected: 0,
    bearFVGsDetected: 0,
    bullInversions: 0, // Originally bullish FVGs that inverted (moved to bullInv)
    bearInversions: 0, // Originally bearish FVGs that inverted (moved to bearInv)
    bullSignals: 0,
    bearSignals: 0,
    zonesInvalidated: 0,
    sessionGapsFiltered: 0
};

// Validation function
function validateFVG(fvg) {
    return fvg &&
        typeof fvg.left === 'number' && fvg.left >= 0 &&
        typeof fvg.top0 === 'number' && typeof fvg.bot0 === 'number' &&
        fvg.top0 > fvg.bot0 &&
        Math.abs(fvg.mid0 - (fvg.top0 + fvg.bot0) / 2) < 0.0001;
}

// Helper function to detect session gaps (overnight gaps in stocks)
function isSessionGap(currentBar, prevBar) {
    // If filtering is disabled, never consider it a session gap
    if (!filterSessionGaps) return false;

    // If open is significantly different from previous close, it's likely a session gap
    const gapThreshold = sessionGapThreshold / 100; // Convert percentage to decimal
    const prevClose = close[prevBar];
    const currentOpen = open[currentBar];

    if (prevClose == null || currentOpen == null) return false;

    const gapSize = Math.abs(currentOpen - prevClose) / prevClose;
    return gapSize > gapThreshold;
}

// Main processing loop
const dataLength = close.length;
for (let i = 2; i < dataLength; i++) {
    // Data validation
    if (high[i] == null || low[i] == null || close[i] == null || open[i] == null ||
        high[i - 1] == null || low[i - 1] == null || close[i - 1] == null ||
        high[i - 2] == null || low[i - 2] == null || close[i - 2] == null ||
        high[i] < low[i] || high[i - 1] < low[i - 1] || high[i - 2] < low[i - 2]) {
        continue;
    }

    try {
        // Skip FVG detection if there are session gaps in the 3-bar pattern
        // This prevents detecting overnight gaps as FVGs
        if (isSessionGap(i, i - 1) || isSessionGap(i - 1, i - 2)) {
            debugCounters.sessionGapsFiltered++;
            continue;
        }

        // FVG Detection
        // Only detect FVGs during continuous trading (no session gaps)
        const bullFVG = (low[i] > high[i - 2]) && (close[i - 1] > high[i - 2]);
        const bearFVG = (high[i] < low[i - 2]) && (close[i - 1] < low[i - 2]);

        const bullGapWidth = bullFVG ? Math.abs(low[i] - high[i - 2]) : 0;
        const bearGapWidth = bearFVG ? Math.abs(low[i - 2] - high[i]) : 0;
        const currentMinWidth = minWidth[i] || 0;

        const validBullFVG = bullFVG && bullGapWidth > currentMinWidth;
        const validBearFVG = bearFVG && bearGapWidth > currentMinWidth;



        // Optional: Mark seed FVGs
        if (showSeeds) {
            if (validBullFVG) { seedTop[i] = low[i]; seedBot[i] = high[i - 2]; }
            if (validBearFVG) { seedTop[i] = low[i - 2]; seedBot[i] = high[i]; }
        }

        // Create FVG objects
        if (validBullFVG) {
            const newFVG = {
                left: i - 1,
                top0: low[i],
                bot0: high[i - 2],
                mid0: (low[i] + high[i - 2]) / 2,
                dir: 1,
                state: 0,
                signaled: false,
                alive: false,
                endIndex: null,
                xIndex: null
            };

            if (validateFVG(newFVG)) {
                bulls.push(newFVG);
                debugCounters.bullFVGsDetected++;
            }
        }

        if (validBearFVG) {
            const newFVG = {
                left: i - 1,
                top0: low[i - 2],
                bot0: high[i],
                mid0: (low[i - 2] + high[i]) / 2,
                dir: -1,
                state: 0,
                signaled: false,
                alive: false,
                endIndex: null,
                xIndex: null
            };

            if (validateFVG(newFVG)) {
                bears.push(newFVG);
                debugCounters.bearFVGsDetected++;
            }
        }

        // Inversion Detection
        const currentCBot = c_bot[i];
        const currentCTop = c_top[i];

        // FVG Management - Move to inversion arrays
        // Bull FVG inversions - move to bullInv (originally bullish FVGs that will invert)
        for (let j = bulls.length - 1; j >= 0; j--) {
            const fvg = bulls[j];
            if (fvg.dir === 1 && currentCBot < fvg.bot0) {
                fvg.xIndex = i; // Mark inversion bar
                bullInv.push(bulls.splice(j, 1)[0]); // Move to inversion array
                debugCounters.bullInversions++;
                inversionDots[i] = fvg.mid0;
            }
        }

        // Bear FVG inversions - move to bearInv (originally bearish FVGs that will invert)
        for (let j = bears.length - 1; j >= 0; j--) {
            const fvg = bears[j];
            if (fvg.dir === -1 && currentCTop > fvg.top0) {
                fvg.xIndex = i; // Mark inversion bar
                bearInv.push(bears.splice(j, 1)[0]); // Move to inversion array
                debugCounters.bearInversions++;
                inversionDots[i] = fvg.mid0;
            }
        }

        // Inversion Management
        // Process bullInv array (originally bullish FVGs that inverted)
        for (let fvg of bullInv) {
            if (fvg.state === 0) {
                fvg.state = 1;
                fvg.dir = -1; // Flip to bearish after inversion
                fvg.alive = true;
                fvg.endIndex = null;
            }
            if (fvg.state >= 1) {
                // Extend the zone to current bar
            }
        }

        // Process bearInv array (originally bearish FVGs that inverted)
        for (let fvg of bearInv) {
            if (fvg.state === 0) {
                fvg.state = 1;
                fvg.dir = 1; // Flip to bullish after inversion
                fvg.alive = true;
                fvg.endIndex = null;
            }
            if (fvg.state >= 1) {
                // Extend the zone to current bar
            }
        }

        // Signal Generation
        if (i > 0) {
            // Bearish signals from bullInv (originally bullish FVGs, now bearish)
            for (let fvg of bullInv) {
                if (fvg.dir === -1 && fvg.state === 1 && !fvg.signaled) {
                    const currentClose = close[i];
                    const prevPrice = useWickRetest ? high[i - 1] : close[i - 1];

                    if (currentClose < fvg.bot0 &&
                        prevPrice >= fvg.bot0 &&
                        prevPrice < fvg.top0) {
                        bearRet[i] = true;
                        fvg.signaled = true;
                        debugCounters.bearSignals++;
                    }
                }
            }

            // Bullish signals from bearInv (originally bearish FVGs, now bullish)
            for (let fvg of bearInv) {
                if (fvg.dir === 1 && fvg.state === 1 && !fvg.signaled) {
                    const currentClose = close[i];
                    const prevPrice = useWickRetest ? low[i - 1] : close[i - 1];

                    if (currentClose > fvg.top0 &&
                        prevPrice <= fvg.top0 &&
                        prevPrice > fvg.bot0) {
                        bullRet[i] = true;
                        fvg.signaled = true;
                        debugCounters.bullSignals++;
                    }
                }
            }
        }

        // Post-inversion invalidation
        for (let j = bullInv.length - 1; j >= 0; j--) {
            const fvg = bullInv[j];

            if (fvg.state >= 1 && fvg.alive !== false) {
                const shouldInvalidate = (fvg.dir === -1 && currentCTop > fvg.top0) ||
                    (fvg.dir === 1 && currentCBot < fvg.bot0);
                if (shouldInvalidate) {
                    fvg.alive = false;
                    fvg.endIndex = i;
                    debugCounters.zonesInvalidated++;
                }
            }
        }

        for (let j = bearInv.length - 1; j >= 0; j--) {
            const fvg = bearInv[j];

            if (fvg.state >= 1 && fvg.alive !== false) {
                const shouldInvalidate = (fvg.dir === -1 && currentCTop > fvg.top0) ||
                    (fvg.dir === 1 && currentCBot < fvg.bot0);
                if (shouldInvalidate) {
                    fvg.alive = false;
                    fvg.endIndex = i;
                    debugCounters.zonesInvalidated++;
                }
            }
        }

        // Memory management
        if (bulls.length >= BUFFER) bulls.splice(0, bulls.length - BUFFER + 10);
        if (bears.length >= BUFFER) bears.splice(0, bears.length - BUFFER + 10);
        if (bullInv.length >= BUFFER) bullInv.splice(0, bullInv.length - BUFFER + 10);
        if (bearInv.length >= BUFFER) bearInv.splice(0, bearInv.length - BUFFER + 10);

    } catch (error) {
        console.warn('IFVG processing error at bar ' + i + ':', error);
        continue;
    }
}

// Drawing logic - fill series for recent zones
// Display zones from all arrays (original + inverted)
// We need to include both original arrays (bulls, bears) and inversion arrays (bullInv, bearInv)
const recentBulls = bulls
    .filter(z => z.xIndex !== undefined && z.xIndex !== null)
    .slice(-disp_num);

const recentBears = bears
    .filter(z => z.xIndex !== undefined && z.xIndex !== null)
    .slice(-disp_num);

const recentBullInv = bullInv
    .filter(z => z.xIndex !== undefined && z.xIndex !== null)
    .slice(-disp_num);

const recentBearInv = bearInv
    .filter(z => z.xIndex !== undefined && z.xIndex !== null)
    .slice(-disp_num);

const allZones = recentBulls.concat(recentBears, recentBullInv, recentBearInv).sort((a, b) => a.xIndex - b.xIndex);

// Fill drawing series
for (let i = 0; i < close.length; i++) {
    for (let k = 0; k < Math.min(allZones.length, maxZones); k++) {
        const zone = allZones[k];

        // Pre-inversion segment
        if (i >= zone.left && i <= zone.xIndex) {
            preTopSeries[k][i] = zone.top0;
            preBotSeries[k][i] = zone.bot0;
        }

        // Post-inversion segment
        let maxRight;
        if (zone.endIndex !== null && zone.endIndex !== undefined) {
            maxRight = zone.endIndex;
        } else if (extendZones && zone.alive !== false) {
            maxRight = Math.min(i + proj_len, close.length - 1);
        } else {
            maxRight = zone.xIndex;
        }

        if (i >= zone.xIndex && i <= maxRight) {
            postTopSeries[k][i] = zone.top0;
            postBotSeries[k][i] = zone.bot0;
        }

        // Midline
        if (showMidlines) {
            const totalRight = Math.max(zone.xIndex, maxRight);
            if (i >= zone.left && i <= totalRight) {
                midSeries[k][i] = zone.mid0;
            }
        }
    }
}

// Visual rendering
if (showSeeds) {
    const seedTopRef = paint(seedTop, { hidden: true, color: '#88888822' });
    const seedBotRef = paint(seedBot, { hidden: true, color: '#88888822' });
    fill(seedTopRef, seedBotRef, '#88888811');
}

// Paint zones
for (let k = 0; k < Math.min(allZones.length, maxZones); k++) {
    const zone = allZones[k];
    if (!zone) continue;



    // Color assignment based on zone.dir
    let preColor, postColor;
    if (colorByLocation) {
        // Override: color by location relative to current price
        const currentPrice = close[close.length - 1];
        const zoneAbovePrice = zone.bot0 > currentPrice;
        preColor = zoneAbovePrice ? red : green;
        postColor = zoneAbovePrice ? red : green;
    } else {
        // Standard logic: zone.dir determines colors
        // For non-inverted zones, use original direction
        // For inverted zones, use flipped direction (already stored in zone.dir)
        if (zone.dir === -1) {
            preColor = green;  // dir=-1 zones are green pre-inversion
            postColor = red;   // dir=-1 zones are red post-inversion
        } else {
            preColor = red;    // dir=1 zones are red pre-inversion
            postColor = green; // dir=1 zones are green post-inversion
        }
    }



    // Paint midline first
    if (showMidlines) {
        paint(midSeries[k], { color: midCol, style: 'dotted', thickness: 1 });
    }

    // Paint zone segments
    const preTopRef = paint(preTopSeries[k], { hidden: true, color: preColor });
    const preBotRef = paint(preBotSeries[k], { hidden: true, color: preColor });
    const postTopRef = paint(postTopSeries[k], { hidden: true, color: postColor });
    const postBotRef = paint(postBotSeries[k], { hidden: true, color: postColor });

    // Fill zones
    fill(preTopRef, preBotRef, preColor);
    fill(postTopRef, postBotRef, postColor);
}

// Optional: Show inversion dots
if (showInversionDots) {
    paint(inversionDots, { name: 'Inversion Points', color: midCol, style: 'dotted', thickness: 1 });
}

// Signal registration
register_signal(bearRet, 'Bearish IFVG Signal');
register_signal(bullRet, 'Bullish IFVG Signal');

Add to TrendSpider

Terms and Conditions

THE INFORMATION PROVIDED THROUGH ANY CONTENT (“CONTENT”) PUBLISHED ON OR PROVIDED THROUGH THE MARKETPLACE (“MARKETPLACE”) SUPPORTED BY TRENDSPIDER LLC (“TRENDSPIDER”) IS PROVIDED "AS IS" AND "AS AVAILABLE" BY THIRD PARTIES AND NOT BY TRENDSPIDER OR ANY OF ITS AFFILIATES. TRENDSPIDER DOES NOT WARRANT THE ACCURACY, COMPLETENESS OR TIMELINESS OF ANY MARKET INFORMATION, FEATURES, TOOLS OR OTHER ITEMS (“INFORMATION”) MADE AVAILABLE THROUGH ANY CONTENT. TRENDSPIDER EXPRESSLY DISCLAIMS ALL WARRANTIES, EITHER EXPRESS OR IMPLIED, PERTAINING TO THE MARKETPLACE, THE CONTENT OR ANY INFORMATION MADE AVAILABLE THROUGH ANY CONTENT, INCLUDING, WITHOUT LIMITIATION, IMPLIED WARRANTIES OF MERCHANTABILITY, ACCURACY, FITNESS FOR A PARTICULAR PURPOSE, AND NON-INFRINGEMENT. TRENDSPIDER EXPRESSLY DISCLAIMS ALL LIABILITY FOR ERRORS OR OMISSIONS IN, OR THE MISUSE OR MISINTERPRETATION OF, ANY INFORMATION MADE AVAILABLE THROUGH ANY CONTENT.

YOU ASSUME THE ENTIRE RISK AS TO THE USE OF ANY INFORMATION MADE AVAILABLE THROUGH ANY CONTENT. UNDER NO CIRCUMSTANCES WILL TRENDSPIDER OR ITS AFFILIATES, AGENTS, OR EMPLOYEES BE LIABLE FOR ANY DAMAGES OF ANY KIND THAT RESULT FROM THE USE OF, OR THE INABILITY TO USE, ANY CONTENT, OR ANY RELAINCE ON ANY INFORMATION MADE AVAILABLE THROUGH ANY CONTENT, EVEN IF ANY SUCH PARTY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

The Content is for informational, educational and entertainment purposes only. Although Content may make available Information relating to investment approaches and opportunities to buy or sell securities, you should not construe any Information made available through any Content as legal, tax, investment, financial or other advice. Nothing contained in any Content constitutes a solicitation, recommendation, endorsement, or offer to buy or sell any securities or other financial instruments. Investing involves risk and you alone assume the sole responsibility of evaluating the merits and risks associated with the use of any Information made available through any Content before making any decisions. You agree not to hold TrendSpider or its affiliates, agents or employees liable for any possible claim for damages arising from any decision you make based on Information made available through any Content.

Some free Content may require a separate subscription to paid Content in order to fully function. TrendSpider makes no representation or warranty as to the level of functionality of any Content offered on the Marketplace and hereby expressly disclaims any such warranty.

Unless otherwise indicated in the Marketplace, TrendSpider is not responsible for billing or user entitlement matters. Any issues pertaining these matters should be directed to the publisher of the Content.

Cancel Accept and continue
